Home » Products » Automatic Measuring Dosing Cup Placement & Pressing Machine

Automatic Measuring Dosing Cup Placement & Pressing Machine

Automatic Measuring Dosing Cup Placement & Pressing Machine
Automatic Measuring Dosing Cup Placement & Pressing Machine
Product Code : NMCPP-150
Product Description
Automatic Measuring Dosing Cup Placement & Pressing Machine:

Description:
Automatic Measuring / Dozing Cup Placement & Pressing machine is highly efficient machine with elegant look, consists of conveyor, vibrator, feed worm, container holding star plate & pressing plate. All the exposed parts of the unit are in S.S., chrome platted or cladded with S.S. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet  and doors are provided to facilitate the servicing of machine.

Operation:
The feed container moving on conveyor belt are feed into an In-feed wheel through In-feed worm, star wheel bringing the sealed container below the pressing plate, mean while the sealed bottle pickup a cup from the delivery chute of bowl, where the body and the neck of the container are positioned below the pressinf plate, where the pressing plate press cup gradually & performing perfect operation of cup pressing.

Techincal Specification:

Model
NMCPP - 150
Output / Hour
3600 to 9000 Bottles
Direction of movement
Left to Right

Electrical
Specification
Main Motor
0.75 HP / 220 Volts / 50 Hz.
Cap Feeding Bowl
300 Watt Magnetic Coil
Height of Conveyor
860 mm to 910 mm
Machine Dimension
2135 mm (L) x 1020 mm (W) x 1800 mm
Case Dimension
2250 mm (L) x 1150 mm (W) x 2200 mm
Net Weight
500 Kgs.
Gross Weight
850 Kgs.
Change Parts Required (A) Container: Star Wheel, Black Guide, Feed Worm.
(B) Cap: Delivery chute, bowl.

Input Specification:

Dozing Cap Specification Diameter 19 mm to 38 mm
Height 15 to 18.3 mm


Container Size
Round Shape (A) Ø22 mm to Ø100 mm Respectively Height 58 mm x 240 mm
(Height option for other bottle height available)
Flat  / Square
(A) 15 mm to 10mm (Length) Respectively 10 mm to 58 mm (Width)
Respectively Height 58 mm x 240 mm
(Height option for other bottle height available)

Salient Features:
  • No container no cuo arrangement.
  • SS elegantly matt finished body.
  • Since motor synchronizes conveyor, star wheel & plateform turret.
  • Adjustable height of conveyor belt, to align with other machine of the line.
  • Specially designed hopper is provided to increase storage capacity of bowl.
  • Low noise level, low power consumptions.
  • <font size="2" face="verdana,arial,h
